Series EC2 Evaporative condensers Specification

    The advantages of structure of our evaporative condenser are novelty, unique and reasonable. The equipment is a collection of condenser, cooling tower, water pond and water pump, which can be put on the top of the roof. The piping system is so simple to reduce the installation material, construction period and installation cost. Our products are widely applicable to cooling systems in steel, food processing, freezing, beer , beverage, petroleum, chemical engineering, coal , chemical fertilizers, medicine and other trades.
一、Model Selection：
　　 Heat Rejection Method:
　　1、Establish total heat rejection required by the system.
　　2、Determine the design conditions for condensing temperature and wet bulb temperature.
　　3、Using the appropriate factor, determine the correction factor to be applied to the system heat rejection.
　　4、Multiply the correction factor by the total system beat regection
　　5、Using Table, select the evaporative condenser whose base total heat rejection equls or exceeds the corrected
       heat rejection calculated in step 4.


二、Base Capacity(KW)：
Model Number EC2- 50 65 80 90 105 120 135 150 165 180 200 210 230 260
Base Heat Rejection (KW) 215 280 345 388 452 517 582 646 711 775 862 905 991 1120
Model Number EC2- 285 320 370 415 440 485 505 520 540 580 700 800 920 1075
Base Heat Rejection (KW) 1228 1379 1594 1788 1896 2089 2176 2213 2326 2499 3016 3446 3963 4631

三、Service：
    The above specification is our standard products. We can produce non-standard products. Service line：0086-575-82156789。
